Battery asset tracker

Low profile.
Finds it indoors.

Name: IQ-BATT-5
Brand: AirIQ

The slim one. Sealed tight enough for a washdown bay, rated cold enough for a northern winter, and it keeps reporting when the asset gets pulled inside and GPS gives up.

Get a quote IQ-BATT-3 or IQ-BATT-5?

IP69K

Sealed against washdown, not just weather

−40°C

Rated from −40°C to +75°C

Wi‑Fi

Indoor positioning where GPS can't reach

2 x AA

Lithium cells, replaceable in the field

Indoor location

GPS needs sky. Your assets don't always have any.

Pull a trailer into a shop, stack a container under a roof, park a lift inside for the winter, and a GPS-only tracker goes quiet. The asset hasn't moved. You just can't see it any more.

IQ-BATT-5 also reads the Wi-Fi networks around it and works out its position from those. Indoors, it still reports.

GNSS outdoors: concurrent GPS and GLONASS, under 3 m accuracy
Wi-Fi BSSID positioning indoors, no reader or gateway to install
BLE 5.2 onboard

Built for the worst of it

Washdown bays and February.

IP68 and IP69K, so pressure washing is not an event. Rated from −40°C to +75°C, which covers a prairie winter and a sun-baked container roof in the same spec line.

IP68 and IP69K sealed enclosure
−40°C to +75°C, 95% humidity non-condensing
Light sensor flags the housing being opened or the tracker pulled off
Accelerometer for movement, tilt and rotation

Excavator parked on rocky ground at a remote site

Two battery trackers

IQ-BATT-3 or IQ-BATT-5?

Both mount without wiring and both run for years on hardware-store lithium cells. They part ways on where the asset actually sits.

Choose IQ-BATT-3 when the asset lives outside

Three cells instead of two, and it holds far more onboard when there's no signal, so a container in a dead zone for weeks still hands over the whole history. It's the workhorse for yards, lots and open ground.

Choose IQ-BATT-5 when it goes indoors, gets washed, or gets cold

Wi-Fi positioning covers the indoor gap, IP69K survives a pressure washer, and the −40°C rating covers winters IQ-BATT-3 isn't rated for. It's also slimmer, which matters on anything with nowhere obvious to put a box.

Compare them side by side See IQ-BATT-3

In practice

Put it on, walk away.

What the spec lines below mean for something sitting in a yard with nothing plugged into it.

Report as often as the asset deserves

One to four reports a day gives the longest battery life, and reports can start at a set time. Motion, timer and exception-based reporting are all on the table.

It keeps its notes when the signal drops

256 records held onboard and sent once coverage comes back, so a gap in the network isn't a gap in the history.

You hear about it when it tips or turns

The accelerometer reads movement, tilt and rotation, which covers everything from a bin being emptied to a road sign being knocked flat.

Tampering shows up as an alert

A light sensor inside the housing notices when it's opened or the tracker is pulled off an asset, so removal isn't silent.

High-volume assets get affordable

This is the low-cost end of the line, which is what makes tagging hundreds of bins, pallets or signs a real plan rather than a budget conversation.

It lands on the same map as everything else

Trailers, equipment and trucks all report into one account, on one map.

Tech specs

IQ-BATT-5, in full.

Power

Batteries: 2 x AA lithium thionyl chloride, 3.6V, non-rechargeable
Supercapacitor: Assisted supercap, 2.5F 5V, for burst transmit current
Operating voltage: 3.5V to 3.65V
Reporting: One to four reports a day gives the longest life. Motion, timer and exception-based reporting are all supported

Housing

Rating: IP68 and IP69K, sealed against washdown as well as weather
Dimensions: 107 x 80 x 25 mm (4.2 x 3.1 x 1.0 in)
Operating temperature: -40°C to +75°C (-40°F to +167°F)
Humidity: 95% RH at 50°C, non-condensing
Mounting: Extra-strong magnet mounts available as an accessory

Location

Outdoors: GNSS, concurrent GPS and GLONASS
Position accuracy: Under 3 m CEP-50
Indoors: Wi-Fi BSSID positioning, so an asset parked inside a shop or warehouse still reports
Bluetooth: BLE 5.2

Connectivity

Network: LTE-M (Cat-M1) and NB-IoT (NB1 and NB2), power class 3
SIM: 4FF nano SIM
Store and forward: 256 records held onboard when the asset is out of coverage

Onboard sensors

Motion: 3-axis accelerometer. Movement, tilt and rotation, for rotation counting and tamper alerts
Light: Detects the housing being opened or the tracker being removed

All specifications are typical and subject to change without notice.

Take it with you

Solution sheet

One page, no form. Forward it to whoever signs off on the fleet budget.

IQ-BATT-5 solution sheetLow-profile battery asset tracking · Wi‑Fi indoors, IP69K, rated to −40°C Download →

Common questions

Asked about IQ-BATT-5.

How is this different from IQ-BAT?

Three things. IQ-BATT-5 is slimmer, it's sealed to IP69K and rated from −40°C instead of −20°C, and it adds Wi-Fi positioning so an asset parked indoors still reports. IQ-BATT-3 runs on three cells instead of two and holds far more records onboard when it's out of coverage. If your assets sit outside in the open, IQ-BATT-3 is the workhorse. If they go indoors, get washed down, or live somewhere genuinely cold, this is the one.

How does it find an asset parked indoors?

GPS needs sky. Inside a shop, a warehouse or a container yard stack, it goes quiet. IQ-BATT-5 also reads the Wi-Fi networks around it and uses those to work out where it is, so a trailer pulled into a building still reports a position instead of dropping off the map.

What can I put it on?

Anything with no power to it: dry vans, flatbeds, shipping containers, pallets, harvest bins, generators, road signs, dumpsters, portable lights, scaffolding. If it sits still and it's worth finding, it's a candidate.

How is it mounted?

Extra-strong magnet mounts are available as an accessory, so most installs are a matter of putting it where you want it. There's no wiring and no install appointment.

How often should it report?

One to four times a day is the sweet spot for battery life, and you can start reports at a set time. It can also report on motion, on a timer, or only when something happens that you care about, so a tracker on a container that never moves isn't burning power saying so.

Does it report into the same place as my trucks?

Yes. Trailers and equipment appear on the same map as your vehicles, in one account.

Is there a contract?

No. Every AirIQ subscription is month-to-month, with no auto-renewal and no early-termination fee. Cancel by calling 1-888-606-6444.
